- Sturdy frame painted with anti-corrosive treatment.
- Stainless steel cover panels.
- Low voltage (24V) control panel with start-delta id system.
- Handy lance and gun storage.
- High filtering capacity cartridge suction filter 300 industrial wheels with brake.
- Electric motor (1400 г. rpm) 20,25 and 30 hp TW 500.
- Premium pumps/TW Motor-pump coupling by means of a flexible joint.
- Automatic unloader valve with external ed bypass and gradual pressure restoring (on 5018 and 5021 models).
- Overheating thermostatic valve.
- Low voltage (24V) start-up panel (star-delta) s.
- Remote switch and motor cut-out with thermal relay.
- Emergency stop button.
- Hour counter.
- Hose reel with 20 mt hose can be mounted on request (cod. 00080-01521).
On request 60hz
Technical Data:
|
Lena 5015 E LP |
|
| Code |
36019-00068 |
| Rated/max pressure |
500/520 bar – 7252/7541 psi |
| Max delivery flow rate |
900 l/h – 4.3 gpm |
| Abs. power/supply |
15000 W/ 380-415 V 3 – 50Hz |
| Motor power |
15 Kw |
| Pump model |
Tw 500/ 1400 rpm |
| T max water inlet |
60*C |
| Dimension (cm)/weight |
118,5x74x100/215 Kg (473 lbs) |
| Lena 5021 E LP |
Lena 5021 E LP |
| 36019-00069 |
36019-00070 |
| 500/520 BAR – 7252/7541 psi |
500/520 BAR – 7252/7541 psi |
| 1110 l/h – 4.8gpm |
12600 l/h – 5.55gpm |
| 19000 W/ 380-415 V 3 – 50Hz |
23000 W/ 380-415 V 3 – 50Hz |
| 18,5 Kw |
22 Kw |
| Tw 500/ 1400 rpm |
Tw 500/ 1400 rpm |
| 60*C |
60*C |
| 118,5x74x100/260 Kg (496 lbs) |
118,5x74x100/285 Kg (507 lbs) |
| Lena 2042 E LP |
| 36019-00074 |
| 200/215 bar – 2900/3118 psi |
| 2520 l/h – 11.09 gpm |
| 18500 W/380-415V 3-50 Hz |
| 18,5 Kw |
| TW / 1400 rpm |
| 60*C |
| 118,5x74x100/225 Kg (496 lbs) |
