- 4 poles electrical motor (1400 rpm) with thermal protection and water cooling.
- Three ceramic pistons, Nickel plating brass linear pump head with high temperature water seals and bushing.
- Integrated elastic joint, for best pump coupling.
- Low voltage and delayed Total Stop.
- Vertical burner.
with high thermal efficiency steel coil. - High pressure detergent flow with 22 liters integrated detergent tank.
- Auxiliary motor for burner air-cooling and two ways fuel pump.
- Temperature regulation gauge with high sensitive stainless steel sensor.
- Header tank and antiscale device.
- Pressure accumulator for hose and gun vibrations prevention.
- Hose reel (optional).
Technical Data:
| HTR 2015 LP | |
| Code | 36074-00040 |
| Rated/max pressure | 200/230 bar – 2900/3335 ps |
| Max delivery flow rate | 900 l/h – 3.96 gpm |
| Abs. power/supply | 7300 W/400V 3~50Hz |
| Motor power | 5,5 kW |
| Pump model | CL6.0 Ni/1400 rpm |
| T max water inlet | 60/110 °C |
| Dimension (cm)/weight | 125x69x89/169 Kg (372 lbs) |
| HTR 2021 LP | HTR 2515 LP |
| 36074-00041 | 36074-00052 |
| 200/230 bar – 2900/3335 psi | 250/280 bar – 3600/4061 psi |
| 1260 l/h – 5.55 gpm | 900 l/h – 3.96 gpm |
| 9700 W/400V 3~50Hz | 8700 W/400V 3~50Hz |
| 7,5 kW | 7,5 kW |
| CL6.0 Ni/1400 rpm | CL6.0 Ni/1400 rpm |
| 60/110 °C | 60/110 °C |
| 125x69x89/171 Kg (376 lbs) | 125x69x89/173 Kg (381 lbs) |
